24
Figure 4. Dimensional drawing SF30A-
Type
A
B
SF30A-01-RX, SF30A-01-RA-BS
G1 1/4
G1 1/4
SF30A-01-UX, SF30A-01-UA-BS
NPT 1 1/4
NPT 1 1/4
