36
SF15A-KIT1 SF15A-KIT2 SF15A-KIT3 SF15A-KIT4 SF051015A-AL-VAL
OSANUMERO NIMI KOODI MÄÄRÄ 13128530 13128580 13128640 13128680 13128485
1 TULPPA SGA-1-SS-M8 12407000 1 X
2 O-RENGAS 6,1X1,6 12680900 1 X X X
3 SÄÄTÖTULPPA. SF051015A KOOTTU 13128700 1 X
4 O-RENGAS 25,3X2,4 VITON 13681300 1 X X X X
5 JOUSI 15-17 Fe 13770950 1 X
6 O-RENGAS 20,2 X 3 VITON 13681450 2 X X X X
7 LAIPPA SF15A 13400250 2 X X X
8 LASIPUTKI SF15A 13771250 1 X X X
9 KARTIO SF15A 13771200 1 X X
10 UIMURI SF15A 13771300 1 X X
11 PTFE-RENGAS SF15A 13400535 1 X X
12 O-RENGAS 8,1X1,6 VITON 13680950 1 X X
13 SF051015A-AL-VALVE 13128485 1 X
14 O-RENGAS 13,3X2,4 VITON 13681150 1 X X
Figure 14. SF20 spare parts and spare part kits
260066
SF20A
KIT1
SF20A
KIT2
SF20A
KIT3
SF20A
KIT4
SF20A-AL-VALVE
ITEM NAME CODE
NUM-
BER
13128540 13128590 13128650 13128732 13128495
1 PLUG SGA-1-SS-M8 12407000 1 X
2 O-RING 6.1X1.6 12680900 1 X X X
3
ADJUSTMENT PLUG.
SF20 ASSEMBLY
13128710 1 X
4 O-RING 30.3X2.4 13681400 1 X X X X
5 SPRING 24.5-36 Fe 13771350 1 X
6 O-RING 24.2 X 3 13681550 2 X X X X
7 FLANGE SF20A 13400100 2 X X X
8 GLASS TUBE SF20A 13771500 1 X X X
9 CONE SF20A 13128756 1 X X
10 FLOAT SF20A 13401800 1 X X
11 PTFE-RING SF20A 13400460 1 X X
12 O-RING 8.1X1.6 13680950 1 X X
13 SF20A-AL-VALVE 13128495 1 X
14 O-RING 13.3X2.4 13681150 1 X X
