SKF TIH 100m User Manual

8
SKF TIH 100m
3. Installation of mains plug
A qualified electrician must install a suitable mains plug.
The correct supply voltage is shown in section 2.2.
The wires should be connected as follows:
TIH 100M/230V
Colour of TIH 100m/230V Mains supply terminal
yellow / green ground
blue neutral
brown phase
TIH 100M/MV
Colour of TIH 100m/MV wire Mains supply terminal
yellow / green ground
blue phase
brown phase
Connect the TIH 100M/MV to only two of the three phases
in order to obtain 400-460 V.
