SKF TIH 100m
2.2 Technical data
TIH 100m
Voltage TIH 100M/230V : 230V / 50 - 60Hz
TIH 100M/MV : 400 - 460V / 50 - 60Hz
Tolerance en voltage ± 10%
Recommended line protection 16 A fuse rating for 230 V
10 A fuse rating for 400 - 460 V
Power consumption (maximum) 3,6 kVA for 230 V
4,0 - 4,6 kVA for 400 - 460 V
Temperature control 0 - 250 °C (32 - 482 °F); in steps of 1°
Probe type Thermocouple, K type
Probe maximum temperature 250 °C (482 °F)
Time mode 0 - 60 minutes; in steps of 0,1 minute
Power range 100% - 50%
Demagnetization automatic; residual magnetism <2A/cm
Overall dimensions (w x d x h) 570 x 230 x 350 mm
(22.4 x 9.0 x 13.7 in)
Area between supports (width x height) 155 x 205 mm (6.1 x 8.0 in)
Coil diameter 110 mm (4.3 in)
For minimum bearing bore diameter of
120 mm (4.7 in)
Weight (with yokes) 42 kg (92 lbs)
Workpiece maximum weight Bearing: 120 kg (264 lbs)
Solid component: 60 kg (132 lbs)
Maximum heating temperature approx. 250 °C (482 °F)
Depending on bearing or workpiece
weight. For higher temperatures,
please contact SKF.
m
20
* 97 kg (bearing 23156)
Standard yoke dimensions:
56 x 56 x 296 mm
(2.2 x 2.2 x 11.7 in)
For minimum bearing bore diameter of:
80 mm (3.1 in)
28 x 28 x 296 mm
(1.1 x 1.1 x 11.7 in)
40 mm (1.6 in)
14 x 14 x 296 mm
(0.6 x 0.6 x 11.7 in)
20 mm (0.8 in)
*m
20
represents the weight (kg) of the heaviest SRB 231 bearing that can be heated from 20 to
110 °C (68 to 230 °F) in 20 minutes.
