SKF TKST 11 - Technical Specifications; SKF TKST 11 Technical Data

6 EN
1. 2.
3.
Fig. 3 – Example when listening
1. Direct access button left: volume down
2. Direct access button right: volume up
3. Direct access button center: mute
2. Technical data
Designation TKST 11
Frequency range 30 Hz - 15kHz
Operating temperature -10 to +45°C (14 - 113°F)
Output volume Adjustable in 15 levels
Display Black and white LCD
Sound volume Up & Down
Battery low signal yes
Symbol Battery low
Maximum recorder output 250 mV
Headset with ear defender 32 Ohm (right and left merged)
Auto switch off Yes, after 10 min
Battery 2 × AA Alkaline (included)
Battery lifetime minimum 30 hours (continuous use)
Probe length 70 and 300 mm (2.8 and 11.8 in.)
Weight
- Total weight 1 670 g (3.68 lb)
- Instrument 290 g (0.64 lb)
- Headset 290 g (0.64 lb)
Dimensions handset 230 × 70 × 38 mm (9 × 2.8 × 1.5 in.)
Case dimensions 360 × 110 × 260 mm (14.2 × 4.3 × 10.2 in.)
1. 2.
3.
Fig. 4 – Example when muted
