3. Troubleshooting
Condition Functioning of
lubricator
LED signal Remote signal
(Green and
Yellow)
No power, lubricator
working correctly
No grease
dispensing
No LED signal Open relay
No power, lubricator
in high pressure
alarm
No grease
dispensed
No LED signal Open relay
No power, lubricator
in empty alarm
No grease
dispensed
No LED signal Open relay
No power, lubricator
in internal fault
alarm
No grease
dispensed
No LED signal Open relay
No power, lubricator
in high pressure
warning
No grease
dispensed
No LED signal Open relay
No power, lubricator
in almost empty
warning
No grease
dispensed
No LED signal Open relay
Power ON,
lubricator working
correctly
Lubricator
waiting until
next dispense
Green LED
blinking every
3 seconds
Closed relay
Power ON,
lubricator in high
pressure alarm
Lubricator not
dispensing
Red LED
every 1 second
Open relay
Power ON,
lubricator in
empty alarm
Lubricator not
dispensing
Red LED
every 3 seconds
Open relay
Power ON,
lubricator in
internal alarm
Lubricator not
dispensing
Red LED
every 5 seconds
Open relay
Power ON,
lubricator in high
pressure warning
Lubricator waiting
until next dispense
Yellow LED
every 1 second
10 seconds
closed, 10
seconds open
Power ON,
lubricator in
almost empty
warning (3% left)
Lubricator waiting
until next dispense
Yellow LED
every 3 seconds
3 seconds closed,
10 seconds open
