Remove capscrew locking chain ten-
sioner in place. (Tensioner is located
at bottom left of gearbox).
notate the tensioner as required to
obtain correct chain tension.
Replace
capscrew to lock chain ten-
sioner in place.
IMPORTANT: If the vehicle is used to
carry or pull heavy loads, it is advisable
to change the gear ratio. Contact your
dealer
for optional gears.
The brake mechanism is self-adjusting,
therefore, periodic adjustment is
not re-
quired. However, the brake mechanism
can be checked by depressing brake
control lever. Brake should apply fully
when lever
is Y2" approx. from handle-
bar grip. If it does not, do
not tamper
with the brake, contact your servicing
dealer. Check
the stop light to see it it
functions. If necessary, readjust
switch
position.
18
WARNING: Brake pucks less
than 3/ 16'" must be replaced,
Replacement must be performed
by an authorized Ski-Doo dealer.
Alwavs check the stop light to
seeif it functions.
Ski should be perpendicular to handle-
bar. To align:
Remove bolt handlebar to
steering column.
Remove handlebar
to expose Qn!in""rl
end of steering column.
Reposition
handlebar on so
that it is perpendicular with . install
and tighten bolt to 30-35 It / lbs.
O
NOTE: if c.'orrect spline
is unobtainable at
h"."nri!""h,:~ r ,
move lower steering bracket to
obtain proper location.
steering bracket holes are
slotted),
