A push-pull switch located on right
side
of
cab.
With
engine running! iflu-
minates both headlamp and taillight.
Pull fully
out
to illuminate.
The dimmer switch, located on left side
of handlebar, allows correct selection
of headlamp beam. To obtain high or
low
beam simply depress switch.
A push
button
switch located on
.rig~t
side
of
handlebar. To stop the engine
In
an emergency, press
button
doyvn
into
lower
position. Before re-starunq en-
gine always depress
button
Into re-
leased upper position. The driver of
this vehicle should familiarize
himself
with
the function
of
this'
device by
using it several times on first outing.
Thereby being mentally prepared for
emergency situations requiring its use.
....
WARNING:
If the
button
has
~
been used in an emergency situa-
tion
the
source
of
malfunction should
be determined and corrected before
restarting engine.
A pull switch located on the riqht side
of cab. Attach tether cord
to
Wrist or
other convenient location before star-
ting engine then fully insert tether
cut-
out
cap on receptacle.
O
NOTE: The cap must be used at
all
time
in order to operate the
vehicle.
If emergency engine
"shut
off'
is re-
quired,
"pull"
out
completely the cap
from switch and engine power will
automaticatly be shut "
off
u
•
....
WARNING:
If
the
switch
is used
~
in an emergency situation
the
source
of
malfunction should be de-
termined and corrected before re-
starting engine.
Auto
rewind type located on right hand
side
of
vehicle. To start engine, pull
handle.
A push-pull button located alongside
manual starter handle. Pull and push
button
(2-3 times) to activate primer.
The primer
should always be used
for
cold engine starts.
After
enqme IS
warm
however, it is
not
necessary to
use primer when starting.
The tachometer registers the impulses
of magneto.
Direct-reading dial indi-
cates the number
of revolutions per
minute
(RPM) of
the
engine.
..
CAUTION: The tachometer is
,.
protected by a fuse,
if
tachometer
stops operating check fuse conditio."
and
if necessary replace. The fuse IS
O.
1 amp. Do
not
use a higher rated
fuse as
this
can cause severe damage
to
the
tachometer.
To open cab! unfasten latches on both
sides near footrest where cab meets
frame. Always
lift
cab gently up until
stopped
by restraining device.
....
WARNING:
it
is dangerous
to
run
~
engine
with
cab open. Personal
injury could result.
Located beside
the
chaincase under
the cab! to gain
access/
tilt
cab. Ideal
location
for
spare plugs, belt, rope, etc.
To check fuel level, simply unscrew
fuel tank cap
and
withdraw
dipstick.
....
WARNING:
Never use a lite
~
match
or
open flame
to
check.
fuel level.
5
