15
• Use suitable detectors to find hidden utility lines or
call the local utility company for assistance (contact
with electric lines can lead to re or electrical shock;
damaging a gas line can result in an explosion;
penetrating a water pipe will cause property damage or
an electrical shock)
• Use completely unrolled and safe extension cords with a
capacity of 16 Amps (U.K. 13 Amps)
DURING USE
• The noise level when working can exceed 85 dB(A); wear
ear protection
• Always keep the cord away from moving parts of the tool;
direct the cord to the rear, away from the tool
• Never use the tool without the original protection guard
system
• Do not attempt to cut extremely small workpieces
• Do not work overhead with the power tool (sucient
control of the power tool is not ensured in this working
manner)
• In case of jamming or electrical or mechanical
malfunction, immediately switch o the tool and
disconnect the plug
• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug
AFTER USE
• When you put away the tool, switch o the motor and
ensure that all moving parts have come to a complete
standstill
• After switching o the tool, never stop the rotation of the
accessory by a lateral force applied against it
EXPLANATION OF SYMBOLS ON TOOL
4 Read the instruction manual before use
5 Double insulation (no earth wire required)
6 Wear protective glasses and hearing protection
7 Do not dispose of the tool together with household waste
material
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut o the cord of this tool,
it must be disposed of safely and not left unattended
USE
• On/o 8
- switch on tool by rst pressing knob A forward and
then pulling trigger switch B
- switch o tool by releasing trigger switch B
• Adjusting cutting depth (0-28,5 mm) 9
- loosen clamp C
- set desired cutting depth using scale D
- tighten clamp C
- for an optimal quality cut the saw blade should not
extend more than 3 mm below the workpiece
! only when using blades with a diameter of 89
mm, cutting depth corresponds with value on
cutting depth scale D (for actual depth of cut use
table 0 as reference)
! always make trial cuts first to verify actual line of
cut
• Dust suction !
- connect vacuum cleaner hose E to connection F and
vacuum cleaner as illustrated
! never let the vacuum cleaner hose interfere with
the lower guard or the cutting operation
! do not use vacuum cleaner when cutting metal
• Changing saw blade @
! disconnect the plug
! ensure that the blade has come to a complete
standstill
- set cutting depth to the maximum
- take hex key G from storage H
- push spindle-lock button J and hold it while you
remove blade bolt K by turning hex key G
CLOCKWISE (= in same direction as arrow printed on
saw blade)
! push spindle-lock button J only when tool is at a
standstill
- release spindle-lock button J
- remove ange L
- press knob M with your thumb
- lift up foot N and remove saw blade
! change saw blade with saw teeth and arrow
printed on saw blade pointing in same direction
as arrow on upper guard P
- mount ange L
- rmly tighten blade bolt K by turning hex key G
COUNTER-CLOCKWISE while pushing spindle-lock
button J
- release spindle-lock button J
• Operating the tool #
- set desired cutting depth
- connect plug to power source (light Q turns on
indicating that the tool is receiving power) $
- press knob M with your thumb
- place tool with front end of foot at on workpiece
- tilt tool forward with line-of-cut indicator R lined up with
desired line of cut marked on the workpiece
! ensure that the saw teeth are not engaged into
the workpiece
- switch on the tool
! be aware of the sudden impact when the tool is
switched on
! the tool should run at full speed before the blade
enters into the workpiece
! do not force the tool (apply light and continuous
pressure in order to avoid overheating the blade tips
and, in case of cutting plastics, melting the plastic
material)
! while working, always hold the tool at the
grey-coloured grip area(s) %
- after completing the cut switch o tool by releasing
trigger B
! ensure that the blade has come to a complete
standstill, before you lift the tool from the
workpiece
• Plunge cutting ^
- switch on the tool
! the tool should run at full speed before the blade
enters into the workpiece
- press knob M with your thumb
- tilt tool forward with line-of-cut indicator R lined up with
desired line of cut marked on the workpiece
- gradually move tool forward
! never pull tool backwards
