Skil 5587-RT - Functional Description and Specifications; Circular Saw

-8-
>7,=287*5.<,;29=287*7-"9.,2/2,*=287<
2<,877.,= =1. 95>0 /;86 =1. 98@.; <8>;,. +./8;. 6*4270 *7B
*<<.6+5B*-3><=6.7=<8;,1*70270*,,.<<8;2.<. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
FIG. 1
LOWER GUARD
FOOT
LOWER GUARD
LIFT LEVER
BLADE WRENCH
& STORAGE
AREA
AUXILIARY
HANDLE
BEVEL
ADJUSTMENT
LEVER
BEVEL
TAB
UPPER
GUARD
2;,>5*;"*@
8-.57>6+.; HD5687, HD5687M, 5587
*A26>6*9*,2=2.<
Blade 7-1/4"
Blade arbor hole 5/8" Round
Depth of cut at 90° 2-7/16"
Depth of cut at 45° 1-7/8"
Depth of cut at 51° 1-11/16"
# For tool specifications refer to the nameplate on your tool.
# Guards and handles may vary from depiction.
LOCK
BUTTON
(HD5687,
HD5687M)
TRIGGER
SWITCH
GRADUATED
QUADRANT
MAIN
HANDLE
