• Donotclampthetoolinavice.
• Use completely unrolled and safe extension
cordswithacapacityof16Amps(U.K.13Amps).
DURING USE
•Inrushcurrentscauseshort-timevoltagedrops;
underunfavourablepowersupplyconditions,oth-
er equipment may be affected (if the system im-
pedanceofthepowersupplyislowerthan0,104
+j0,065Ohm,disturbancesareunlikelytooccur);
if you need further clarification, you may contact
yourlocalpowersupplyauthority.
• Ifthecordisdamagedorcutthroughwhilework-
ing, do not touch the cord, but immediately disconnect
theplug;neverusethetoolwithadamagedcord.
• Incaseofelectricalormechanicalmalfunction,im-
mediatelyswitchoffthetoolanddisconnecttheplug.
• Incaseofcurrentinterruptionorwhentheplug
isaccidentallypulledout,unlocktheon/offswitch
J immediately in order to prevent uncontrolled re-
starting.
AFTER USE
• Afterswitchingoffthetool,neverstopthero-
tation of the accessory by a lateral force applied
againstitWHENCONNECTINGNEW3-PINPLUG
(U.K.ONLY):
• Donotconnecttheblue(=neutral)orbrown(=
live)wireinthecordofthistooltotheearthtermi-
nal of the plug.
• Ifforanyreasontheoldplugiscutoffthecord
of this tool, it must be disposed of safely and not
left unattended.
DESCRIPTAL FUNCTION
INTRODUCTION
Thistoolisintendedforgrinding,cuttingandde-
burringmetalandstonematerialswithouttheuse
ofwater;withtheappropriateaccessoriesthetool
can also be used for brushing and sanding.
Themachinecanbeusedonlyfordrycutting.
!
Cutting operations with bonded abrasive
cut-off wheels are only allowed when a cut-off
guard is used. (Figure 9)
Read and save this instruction manual.
TOOL ELEMENTS 2 (Figure 1)
A On/offlockingswitch
B Ventilation slots
C Auxiliaryhandle*
D Protective guard
E Spindle-lockbutton
F Spindle
G Mountingange*
H Grindingdisc*
I Cuttingdisc*
J Clampingange*
K Accessorykey*
L Protectiveguardscrew
M Allenkey*
*Theaccessoriesshownordescribedarenotpartof
theproduct.Checktheavailableaccessoriesinthe
sales program from your country.
TECHNICAL SPECIFICATIONS 1
Angle Gringer 9002 9004
Article Number F 012 900 2.. F 012 900 4..
Power 127-220V [W] 600 700
Frequency  [Hz] 50/60 50/60
Amperege 127V [A] 5.0 5.8
220V [A] 2.9 3.4
No-loadspeed  [/min] 10.000 11.000
Capacity disc Ø
Grinding/cutting [mm] 115(4 1/2”) 115(4 1/2”)
Spindlethread   M14x2 M14x2
WeightaccordingtoEPTA01/2003 [kg] 2,4 2,4
Protection Class / II / II
*ForCentralAméricacountriesspindlethread5/8”.
