Skipper EMES60 - Speed log hardware interface setup screen (screen 5)

26
4.5 Speedlog communication screen (screen 4)
This screen is used to verify the incoming and outgoing data through the system
communication lines (NMEA serial and Light Weight Ethernet).
All data can be logged to a file on disk.
It is also used to setup the communication line parameters (UART setting for
NMEA0183, IP address for Light Weight Ethernet).
Input messages: data messages sent to
the system
Output messages: data messages sent
from the system
Message display controls
Message display controls
Horizontal scroll: touch and drag to see
long messages
Communications port controls
