2 INSTALLATION

PRIORTOINSTALLATION

Performavisualinspectionoftheequipmentforevidenceofdamageincurred
duringshipment.

2.1 ITEMSREQUIREDBUTNOTSUPPLIED;

Table1
QTY ITEMS USE
1 DanielsManufacturingCrimperP/N
M22520/2‐01
P1
1 DanielsManufacturingCrimperPositioner
P/NK1S
AllM24308connectors
 Contactinsertion/removaltool M81969/1‐4(metal)or
M81969/14‐01(plastic)
 Misc.installationssuppliessuchas;wire
ties,Adelclamps,Etc.


2.2 SYSTEMCOMPONENTS
Table2
PartNumber Description
1616‐900‐25 Kit,25D‐subminiature
Forte’typicallyusestwoofanyaccessorylistedbelow,uptofourmaybeinstalled
MMUIIP/N NVGLens POTSAudio Wi‐FiCapable
1616‐055‐10 no yes yes
1616‐055‐12 yes yes Yes
1616‐055‐020 no yes yes
1616‐055‐022 yes yes Yes

