4 POSTINSTALLATIONCONFIGURATION

Notestingcanoccuruntilatransceiverisactivated.Thecustomerisresponsiblefor
thisactivationasthecustomerreceivesthebillsforthephoneuse.Thisprocess
shouldbedoneinadvanceoftheinstallation/testing.

IMPORTANTNOTE

TheMMUIIcomesfromthefactorywithadefaultMessageSet
(MSet)loadedtoallowtheinstallertoperformtestingright
outofthebox.

TheENDUSERMUST!loadtheirownMSetinordertomake
theMMUIIfunctionastheydesire.Creationofthecustomer’s
MSetistheresponsibilityofthecustomer,andmustbedone
withMSetManageSoftware.



4.1 MMUIICONFIGURATION

Priortotesting,assureteMMUIIisconfiguredcorrectlyforthetransceiverand
functionsthatwillberequired.

EnteringInstallerConfigurationmodeisoneCCWpushed‐indetentoftherotary
knobwhilepressingthe‘*’keyfromeithertheReadypage,orfromtheinitialMMU
IIsplashdisplaypage.ThefollowingparametersmaybesetinConfigurationmode:

4.1.1 ConfigVersion‐Internaluse,forinformationalpurposes.Thisdescriptionisvalid
forConfigVersion2.

