Sky Connect DO-160 - Operation

1616-920-03
8/28/2014
Rev: B
1
3 OPERATION

ThefollowingwillcoveroperationissuesontheMMUII.SeetheMMUIIOperator’s
GuideforacompletedescriptionofhowtooperatetheMMUII.

TheMMUIIiscomputercontrolleddialerandveryflexibleinoperation.It
communicatestothetransceiveroveranRS‐232portorPOTSline.

Thisunitcanbeprogrammedintheaircraftwithnewmessagesets.Ithasaneight
stepdimmingfeaturetothedisplay.

TheMMUIIhas32Kofinternalmemory.Thisisenoughstoragefor1000phone
numbers/textmessagesifallthescreencharactersweretobefilled.

TheMMUIIprovidesauserinterfacetoanexternaltransceiver,allowingauserto
controlvoicecallsandsend&receivetextSBDmessages.TheMMUIIcontainsa2‐
line,16characteralphanumericdisplayandarotaryknobwithapushbuttonaction.
ExternalI/OincludesanRS232port,andtwolampdrivers.

TheMMUIIisloadedwitha“MessageSet”,whichissavedinFlashmemory.The
MessageSetcontainsconfigurationdata,thenamesandphonenumberchoicesfor
voicedialing,andthecompletesetoftextmessagesthatcanbeselectedbytheuser
fortransmissiontotheground.

TheMessageSetmaybeloadedonthegroundviatheMMU’sRS232port.

TheMMUIIcommunicateswiththemapapplicationviabinarySBDmessages.
MobileTerminated(“MT”)messagesaresentfromthegroundtotheMMUII
(uplink),andMobileOriginated(“MO”)messagesaresentfromtheMMUIItothe
ground(downlink).ThesemessagesaresenttoandfromtheSkyConnectTracker
Map.Atreleaseofthistext,noothermappingsystemhastheabilitytomakeuseof
textmessagingtoorfromtheaircraft.

MSETManage‐PhonenumbersandmessagesarecreatedfortheMMUIIbyusinga
SkyConnectprogramcalledMSETManage.Thisprogramwillcreateamessageset
ofphonenumbersandcannedmessagestobeloadedintotheMMUIIviaRS‐232
connectionorWi‐Ficonnection.Aconnectorshouldbeinstalledasclosetotheback
oftheMMUIIaspractical,toallowtheRS‐232portbetweenthetransceiverandthe
MMUIItobebroken,andallowtheconnectionofaPCforthispurpose.

TheMMUIIsupportsdrivingtwoannunciatorstoindicatewhenacallormessageis
