Sky Connect DO-160 - Page 29

1616-920-03
8/28/2014
Rev: B
7
4.2.2 MMUIISlaveConfiguration

Step Procedure
S1 ApplyPowertotheSlaveMMUIIController.
S2 WhentheScreendisplaystheMMUVersionandMSetversion,pressand
holdthe*button(UpperRight)andpressthemainKNOBinandturn
oneclickcounter‐clockwise,thenreleaseboththeknobandthe*button.
S3 RotatetheKnob(donotpressin)clockwiseuntiltheDIAL/In‐Call
Mech:pageappears.
S4 ThedisplayprobablyissetatDTMF/DTMF.
S5 Presstheknobandrelease.Theselectionwillbegintoflash.
S6 RotatetheknobuntilthePots/NoTrkrisdisplayed.
S7 Presstheknobandhold.Thescreenwilldisplay“ValueSaved
SUCCESS”.
S8 RotatetheKnob(donotpressin)clockwiseuntiltheVolumeTap:page
appears.
S9 ThedisplayprobablyissetatNOTENABLED.
S10 Presstheknobinandrelease.Theselectionwillbegintoflash.
S11 RotatetheknobuntiltheselectionOffhookdisplayed.
S12 Presstheknobandhold.Thescreenwilldisplay“ValueSaved
SUCCESS”.
S13 Presstheknobinandrotateclockwiseoneclick.Release.
S14 ThescreenshoulddisplayExitSettingsMode.
S15 Presstheknobinandrelease.ThescreenwillnowdisplayMMUReady
page.
S16 SlaveMMUIIConfigurationcomplete.

