SKY-WATCHER CQ350-PRO - Specifications

14
Specications:
Product Name CQ350-PRO Mount
Mount Type German Equatorial Mount
Payload
(Rated for astrophotography; counterweights excluded)
35kg
Latitude Adjustment Range 10º to 70º
Azimuth Adjustment Range ±20 º
Weight (Tripod excluded) 15 kg
Counterweight 2 x 10kg/ea.
Tripod 29.4kg
Counterweight Rod 2.6kg
Power Requirement DC11~16V(Higher voltage preferred), 55W
Motor 0.9 º Hybrid Stepper Motor
Transmission 435:1 Worm Drive
256 Micro-step/0.9º Stepper Motor Drive
RA Gear Diameter 155mm
Resolution 44,544,000 Counts/Rev., approx. 0.03 arc-second
Maximum Slewing Speed 4 degrees/second
Tracking Rate Sidereal rate, solar rate, lunar rate
Tracking Mode Equatorial mode
Auto-guiding Speed 0.125X, 0.25X, 0.5X, 0.75X, 1X
PEC 200 Segments Permanent PEC
GOTO Controller SynScan hand control, SynScan Pro App
Database 42000+ Objects
Celestial Object Catalog Messier, NGC, IC, SAO, Caldwell, Double Star,
Variable Star, Named Star, Planets
Pointing Accuracy Up to 5 arc-minutes (RMS)
Note: The above specications may be changed without advance notice.
APPENDIX: SPECIFICATIONS
