6
3.
PART I: SETTING UP THE CQ350-PRO MOUNT
*Fasten the upper knob enough for the mount to be stable, but not too tightly to still allow
azimuth ne adjustment with the horizontal azimuth adjustment knobs when operating in
polar alignment*
Tighten the lower knob (Fig 1.2c).
5. Tighten thetwoazimuth lockingscrews onto the tripod platform.
Again, tighten the bolts enough for the mount to be stable but not too tightly. This is to allow
azimuth ne adjustment using the horizontal azimuth adjustment knobs.(Fig. 1.2d)
Fig. 1.2d
Fig. 1.2c
Azimuth Locking Screw
mount tightening
upper knob
accessory tray tightening
lower knob
