SKY-WATCHER CQ40 - Page 7

7
RA exible control
cable
Latitude adjustment
lever (up-down)
DEC lination
Clutch knob
DEC exible control
cable
Latitude locking lever
M10 tripod clamping
screw
Right Ascension
Clutch knob
Telescope
clamping knob
Lock handwheel
Slow motion
controls
Counterweight
Counterweight bar
Slide the sleeve end of the RA and DEC exible control cables over the nipples on the end of the worm gear
axis. Fasten the exible control cables using the set screw against the at surface on the nipple (g.5).
Screw the counterweight bar, with the counterweight already on the counterweight bar, in the mount see
(g.5). Lock the counterweight on the counterweight bar with the lock handwheel.
TIP: You can freely choose to attach the exible control cables at one of the two nipple ends of the worm, in
the direction which is more convenient, to have the slow motion controls in reach while observing through the
telescope (g.6).
5.
6.
Fig.4
Fig.6Fig.5
