Sky SKYLAM 1120 - Control Panel

SKYLAM 1120 / 720 / 380
11 10
1. TEMP ▲▼ : Adjust temperature.
2. SPEED ▲▼ : Variable speed from 1~9.
reached.
3. STBY : Temperature is set to 85℃.
10. Rollers are running.
3. MEAS : Measures actual roller temperature.
11. Fans are running.
4. STOP : Stops rollers and Run rollers.
5. REV : Reverse action.
SKY
When the machine is initially turned on, the LCD window will display the last working preset momory setting.
9. READY : When the preset temperature is
6. CONTROL PANEL
Main Switch
(Top Roller Switch)
Bottom Roller Switch
6
