Skyjack SJ 9250 - Left Side

Page 76 Mid Size & Full Size RTs
Engine Powered
Labels Section 5
No. Label Pictorial Description
1
Skyjack Logo
Large Skyjack logo - blue and red
2
Tape Blue/White
Skyjack pinstripe
3
Caution Tape Stripe
Caution stripe
4
Wheel Specifications
Refer to manual for wheel type, offset, pressure and torque.
5
Foam-filled & Wheel load*
Indicate foam-filled tire and rated wheel load.
*Wheel load will vary over different aerial platforms.
Left Side
