Mid Size & Full Size RTs
Engine Powered
Page 79
Section 5 Labels
No. Label Pictorial Description
1
Main Power Disconnect
Main power disconnect lever
2
Relay Names - Upper (Model 71xx)*
Relay names for Model 71xx electrical panel (upper bank)
*Note: Relay names will vary with differing units
3
Relay Names - Lower (Model 71xx)*
Relay names for Model 71xx electrical panel (lower bank)
*Note: Relay names will vary with differing units
4
Ground Circuit Breaker
Push to reset ground circuit breaker.
5
Power Circuit Breaker
Push to reset power circuit breaker.
Electrical Panel and Hydraulic/Fuel Compartment
1
54
6
9
7
8
2 3
Front View Rear View
Side View
