It is the responsibility of the operator to read, completely understand and follow all instructions and warnings
contained in this operating manual and on the aerial platform.
FAMILIARIZATION
2.2-4 Tilt Switch
The tilt switch is located on top of the base control
console. It is designed to prevent driving when aerial
platform is on a slope greater than a predetermined limit.
WARNING
If aerial platform becomes tilted causing
alarm to sound, the platform must be fully
lowered immediately. Ensure that aerial
platform is on a rm level surface before
operating the aerial platform. Refer to
Section 3.11 for instructions regarding
recovery from an inclined position.
2.2-5 Differential Lock Switch
This switch is located on the platform control console.
The differential locking system provides more traction by
providing equal drive to each wheel regardless of traction.
Differential locks are used to prevent from getting stuck
when driving on loose, muddy, or rocky terrain. Refer to
Section 2.4-3 for instruction regarding testing differential
lock switch.
WARNING
Before engaging differential lock, ensure
drive/steer controller is in neutral position.
2.2-6 Footswitch
The footswitch is located on the oor of the platform.
When depressed and held, it enables controls on platform
control console.
Figure 2-4. Footswitch
NOTE
The footswitch is equipped with a 15-second
anti-tiedown feature that deactivates
footswitch when operator depresses it for
15 seconds without activating any function.
SJ 40T & SJ 45T
SJ 61T & SJ 66T
Page 15
Section 2 - Familiarization Control Functions
