Skyjack SJ45 T+ - Page 81

238261AAA SJ40 T+, SJ45 T+
86
Section 7 – Technical Diagrams and Specifications Technical diagrams
Dimensions - SJ45 T+ (continued)
1.60 m
[5 ft 3 in ]
61°
63°
2.82 m
[9 ft 3 in ]
360°
5.18 m
[17 ft ]
F
E
E 0.27 m
F 0.04 m
0.17m
1ft
0.65m
2ft
1.11m
4ft
B
A
C
D
2.44 m/1.83 m
[96 in/72 in]
175°
A 0.91 m
[36 in]
1.62 m
[64 in]
C 1.12m
[3 ft 8 in]
B 2.29 m
[7 ft 6 in]
D 2.24 m
[7 ft 6 in]
