238261AAA SJ40 T+, SJ45 T+
92
Section 7 – Technical Diagrams and Specifications Floor loading pressure
7.8 Floor loading pressure
Model
Weights Pressures
MEWP Weight Weight per Wheel** LCP*** OFL***
kg lb kg lb kPa psi kPa psf
SJ40 T+
Min* 6,586 14,520 1,905 4,200 857 124 8.6 180
Max* 7,041 15,520 3,495 7,700 1,223 177 9.2 192
SJ45 T+
Min* 7,120 15,700 2,041 4,500 884 125 9.3 195
Max* 7,575 16,700 4,082 9,000 1,414 205 9.9 207
2106AA
Min: Minimum MEWP weight (Unloaded platform, no options/attachments)
Maximum MEWP weight (Platform loaded to capacity with options/attachments)
Wheel Load is the weight that can be experienced on one wheel.
Note: This is more than 25% of the machine weight due to possible weight distribution over the machine and platform.
LCP: Local Concentrated Pressure is a measure of how hard the MEWP presses on the area in direct contact with the floor/tire.
OFL: Overall Floor Load (Pressure) is a measure of the average load the MEWP imparts on the whole surface directly underneath
the chassis. This has been calculated by dividing the MEWP weight by the overall floor area occupied by the MEWP (on wheels).
Note: The floor covering (e.g., tile, carpet, etc.) or the structure (e.g., beams) of the operating surface must be able to withstand
more than the values indicated above.
NOTE
The LCP or OFL that an individual surface can withstand varies from structure to structure and is generally
determined by the engineer or architect for that particular structure.
