SkyLine Mirage Series User Manual

©2015 Skyline Exhibits
Printed in U.S.A. PN36547-A
Channel bars hold the graphic to the
frame and are applied to all
quadrants on the front side of the
frame. Extra channel bars are applied
on each end on the back side of the
frame to hold the panels in place.
0020
0021
Top Connection
Connect top channel section to
top hub of display frame.
Center Connection(s) Connect
bottom of top channel to hub of
display frame. Slide top of next
channel up onto same hub.
Bottom Connection
Connect bottom of channel to hub
of display frame.
8
Frame
Hub
Top
Channel
Top
Channel
Center
Channel
Step 6
Step 7
Step 8
6
7
8
Channel Bars
Bottom
Channel
Mirage Classic
Mirage Adantage & Mirage Plus
