Tilt frame forward to reach top
connectors.
Mirage® Classic: The Mirage®
Classic has manual connectors.
When the frame is fully expanded,
lock one center connector to keep
the frame expanded.
Inset: Pull back on yellow sleeve,
place end of connector onto oppo-
site hub and release yellow sleeve
to lock.
Lock all remaining connectors.
7
4
5
Hub
Mirage® Advantage and Plus Models, advance to Step 6
Mirage® Classic
Mirage® Advantage: The Mirage
Advantage has magnetic connectors.
The frame connectors will magneti-
cally snap together when the frame
is fully expanded. Check to make sure
all connectors do join and attach any
that have not.
Mirage® Plus: The Mirage Plus frame
does not have connectors. The frame
will lock into place when it is fully
expanded.
To Next Page
