Skymaster DXS 23 - Features; Technical Data; Service

GB 20
9. Features
10. Technical data
11. Service
• 2000 channels for open access to digital TV- and radio programs
• Electronic program guide (EPG) with
station name and program content
• On Screen Menu (OSD) multilingual
• Teletext with 300 pages memory
• Timer function
• 4-digit programme display
• Loop through to connect analogue receiver
• DiSEqC 1.0
• DiSEqC 1.2
• Stereo audio output
• LNB short circuit proof
• 2 x scart connector
• Software update via satellite
• Measurements: 26,5 x 16,5 x 4 cm
Waste electrical and electronic equipment is classed as recyclable waste and does not belong in domestic refuse!
We therefore request you to actively support the conservation of resources and environmental protection and to dispose of this device
at responsible take back points – if possible.
Tuner
Input Connector 1 x F type
Output Connector 1 x F type 75 Ohm IF signal out
Frequency Range 950 MHz bis 2150 MHz
Input Impedance 75 Ohm
Signal Level -25 bis -65dBm
LNB Power & Polarization Vertikal:+14 V ± 0,5 V
Horizontal:+18 V ± 0,5 V
22kHz Ton Frequenz:22 kHz ± 2 kHz
Demodulation QPSK,
kompatibel mit SCPC und MCPC
Input Symbol Rate 2 - 45 Mbit/s
FEC Decoder Convolutional Code Rate
1/2, 2/3, 3/4, 5/6 und 7/8
MPEG Transport Stream A/V Decoding
Transport Stream MPEG-2 ISO/IEC 13818
Transport Stream Specification
Profile & Level MPEG-2 MP @ ML
Input T/S Data Rate 80Mbit/S Max.
Aspect Ratio AUTO, 4:3 Pan & Scan, 4:3 Letter
Box, 16: 9
Teletext DVB-TXTETSI/EN300472
TV SCART: RGB, FBAS
VCR SCART: RGB, FBAS
S/PDIF Koaxial
Data Interface: RS232C, BAUD Rate
115.200 KHz Max, 9Pin D-SUB
Power Supply
Input voltage AC 230 V, 50 Hz
Standby < 8 W
max. 20 W
Dear Customer!
Please bear in mind that unjustified complaints will cost you money! Please consult our telephone HOTLINE if you need assistance. Here experts will
provide you with speedy advice and tips on localising the cause of a fault. If it transpires that the problem is actually a defective device, please send
it in for repair with a precise description of the fault.
Our HOTLINE:
(D) 0900 1 512 532 (€ 0,25/Min.)
(A) 0900 400 222 (€ 0,64/Min.)
Monday to Sunday from 8.00 - 22.00
SM ELECTRONIC GmbH
Waldweg 2
D-22145 Stapelfeld/Braak
Internet: www.skymaster.de
E-Mail: info@sm-electronic.de
Subject to technical changes
ASTRA, EUTELSAT, TÜRKSAT, DiSEqC and Skymaster are registered trademarks.
