Skytech: 3002
REV. 4-19-12 Page 2
BASIC TRANSMITTER FUNCTIONS
To understand the operation of the transmitter, press and release the MODE button (Fig. 3) until the LCD screen reads
OFF in the display (Fig. 4).
Step 1: Press the MODE button one time to manually turn ON the appliance (Fig. 5).
Step 2: Press the MODE button a second time to put the to put the system in THERMO mode (Fig. 6).
Step 3: Press the MODE button a third time to turn the appliance back OFF again as show in (Fig. 4).
Fig. 4 OFF Mode
Fig. 5 Manual ON
Fig. 6 Thermo Mode
Slide down the lower section of the cover on the front of the transmitter to expose the “SET” buttons (Fig. 1). The slide
cover protects the SET buttons from being changed accidentally. Close the cover after completing the following settings/
programming.
Blinking numbers on the LCD display indicate the system is awaiting user input, such as using the UP and DOWN buttons
to program a new setting. If no change is made to ashing digits within 15-seconds, the system will complete the
procedure last programmed and reset the display to its normal state.
SETTING UP THE TRANSMITTER
SETTING THE CLOCK
1. Press and hold the TIMER/TIME button on the transmitter
for more than 2-seconds (Fig. 7). The hour digit(s) will begin
blinking (Fig. 8)..
2. Press the UP or DOWN button until the desired hour is
displayed in AM or PM.
3. After setting the desired hour, press and release the TIMER/
TIME button again to set the minutes; the minute digits will
begin blinking (Fig. 9)..
4. Press the UP or DOWN button until the desired minutes are
displayed.
5. Press and hold the TIMER/TIME button again for more than
2-seconds. The time digits will cease blinking, indicating the
clock has been successfully set. You may also press the
SET button on the transmitter to stop the time digits from
blinking and set the time.
Fig. 8 SettingHours
Fig. 9 Setting Minutes
Fig. 3 Mode Button
Fig. 7 Timer/Time Button
