current “SWING” setting in the SET TEMP frame. The letter “S” will
display in the ROOM TEMP frame on the LCD screen.
z Press the UP or DOWN button to change the temperature differential
or “SWING” (1-3). See above for 1-3 “SWING” temperature valves.
z To store the “swing number press the SET button or allow 15 seconds
to lapse, and the new “swing number” will be automatically
programmed.
4. Child Proof “Lock-out”:
z To activate the “LOCK-OUT” feature, press and hold the UP and
TIMER/TIME buttons, together, for 5 seconds. The will appear
on the LCD screen.
z To disengage the “LOCK-OUT”, press and hold the UP and TIMER
buttons, together for 5 seconds or more, and the will disappear
from the LCD screen and the transmitter will return to its normal
operating condition.
5. Low Battery ( ) will appear when battery power has dropped
significantly.
6. The System Icon ( ) will be showed if the system is ON.
7. The room temperature always shows on screen, which
range between 32 and 99 Fahrenheit.
8. The Child Proof ( ) will appear on screen if the “Lock-out” Feature is
activation.
9. The Flame icon ( ) , the main flame indicates burner/valve in
operation and additional flame is reserved for specific modulation device.
