Skytech Smart Stat III User Manual

WIRING INSTRUCTIONS
A qualied electrician should install the remote control system.
1 2 3 4 5 6
REMOTE RECEIVER
TERMINAL BLOCK
ON MILLIVOLT
GAS VALVES
TH
TP
TP
TH
THERMOPILE/
PILOT LIGHT
T o 11 0VAC
input
MILLIVOLT VALVES
MILLIVOLT SYSTEM CHECK
Ensure that the pilot ame is lit.•
Slide the 3-position button on the remote receiver to the • ON position. The main gas ame (i.e., the re) should ignite.
Slide the button to • OFF. The main ame should extinguish (the pilot ame will remain on).
Slide the button to • REMOTE, then press the ON button on the transmitter to change the system to on. The main gas ame should
ignite.
Connect one wire from the remote receiver to the TH terminal on the gas •
valve.
Connect the other wire from the remote receiver to the TH/TP terminal on •
the gas valve.
1 2 3 4 5 6
REMOTE RECEIVER
ELECTRONIC MODULE
TR
TH
neutral wire
24VAC
hot wire
110/24VAC
Transformer
T o 1 1 0VAC
input
The remote control receiver can be connected, in series, to a 24VAC transformer to
the TR (transformer) terminal on the ELECTRONIC MODULE. Connect the hot wire
from the 24VAC transformer to either of the wires on the remote receiver. Connect
the other wire from the receiver to the TH (thermostat) terminal on the ELECTRONIC
MODULE.
ELECTRONIC SPARK IGNITION 24 VAC INPUT
ELECTRONIC SPARK IGNITION DRY CONTACT INPUT
I
S
Electronic
Module
Piggyback
Connectors
Switch
Wires
ON
REMOTE
OFF
LEARN
REV. 5-8-13 Page 3
Before installation, make sure you turn the slide switch to • OFF. After installation, make sure you turn the slide switch to REMOTE.
The remote receiver can be placed on the replace hearth or under the replace behind the control access panel. •
Use the wires attached to the remote receiver to connect to the gas valve or the electric module (piggyback connectors have both •
male & female terminals for exibility).
Be sure that the connectors do not touch each other or other bare metal surfaces; this will cause the appliance to turn on. The con-•
nectors may be wrapped with electrical tape to prevent this.
INSTALLATION
Protection from extreme heat is very important. The remote receiver should be kept away from temperatures exceeding 170ºF. Extreme
heat can cause damage, which is not covered under warranty.
