Item Part No. Description
1 3200326 Plate, Instrument Panel (less Components)
2 3240197 Cover Plate
3 3220088 Thumb Screw
4 6139001 Name & Data Plate
5 3240212 End Panel, Welded Assembly
6 3240263 Side Panel, with Logo (2 req’d.)
- 3134024 SkyTracker Logo, Self-Adhesive
7 3240264 Left Side Panel, Motor Housing
8 3200615 Gear Motor, 90 V.DC
- 2140249 Brass Breather Cap, Gearbox
9 3159006 Drive Sprocket, 10 Tooth
10 3240262 End Panel, Motor Housing
11 3133003 Speed Control Assembly
12 4198052 Stand-Off, 8-32 x 1/2" (4 req’d.)
13 3240263 Right Side Panel, Motor Housing
14 3159003 Driven Sprocket, 96 Tooth
15 3198118 Roller Chain
16 3198119 Master Link, Roller Chain
17 3240257 Top Cover, Motor Housing
18 4110045 Duct Clamp
19 3126003 Flexible Air Duct
20 3104005 Ball Bearing
21 3220097 Lower Bearing Housing
22 3136005 Seal
23 3200420 Bent Shaft, Lamphead
24 3220098 Upper Bearing Housing
25 3148001 Snap Ring
26 3240187 Spring Retaining Bracket
27 3220175 Bracket Mounting Plate
28 3220093 Motor Adjusting Stud
- 4258008 Acorn Nut, 1/4-20
- 4258001 Lock Nut, 1/4-20
29 3240258 Base Frame, Welded Assembly
30 3240259 Top Cover Plate
31 3156002 Spacer, 1/4” x 1/4" (4 req’d.)
32 3156003 Spacer, 1/4” x 1/2" (2 req’d.)
- 4251500 Screw, 1/4-20 x 1-1/2" Hex Head
- 4252501 Screw, 1/4-20 x 2-1/2" Hex Head
- 4257104 Flatwasher, 1/4"
PARTS LIST
Figure 2
