Item Part No. Description
1 8240047 Terminal Board Mounting Plate, Phenolic
2 3121005 Fuse, 20 A. 250 V. (replace with same rated fuse)
2 3121038 Fuse, 30 A. 250 V. (replace with same rated fuse)
3 3121054 Fuse Block
4 3108133 Power Factor Capacitor (3 req’d.)
5 3110001 Capacitor Clamp (3 req’d.)
6 3240538 Capacitor Mounting Bracket
7 3270318 Printed Circuit Board Assembly
8 4156002 Spacer, PC Board (4 req’d.)
9 8240040 SupportBracket,RectierHeatSinks
10 8146026 Ceramic Resistor (R1,2), 100 Ohm, 100 W.
11 8240254 Heat Sink Mounting Plate, Phenolic
12 81247000 Shunt, 200 A.
13 3240006 Chassis Plate, Welded Assembly
14 8240255 Heat Sink Mounting Plate
15 8220032 Heat Sink (2 req’d.)
16 8161010 Thermal Switch
17 8147004 Forward Diode (CR1,2,3), 150 A. 300 V. (1N3290A)
18* 6171010 Positive Lead (Red)
19* 6171009 Negative Lead (Black)
- 94129000 Ring Terminal (2 per lead req’d.)
20 8240434 Buss Bar (3 req’d.)
21 8147001 Reverse Diode (CR4,5,6), 150 A. 300 V. (1N3290A-R)
22 8133026 Squirrelcage Blower, 230 V.AC, 50/60 Hz.
23 9164008 PowerTransformer,2000Watt;208/230V.ACInput
23 9164009 PowerTransformer,2000Watt;380/440V.ACInput
23 9164012 PowerTransformer,4000Watt;208/230V.ACInput
23 9164001 PowerTransformer,4000Watt;380/440V.ACInput
23 9164011 PowerTransformer,7000Watt;208/230V.ACInput
23 9164007 PowerTransformer,7000Watt;380/440V.ACInput
Item 23 Transformer includes Item 1 Mounting Plate & (6) Item 25 Terminal Blocks.
24 8114003 Contactor
25 8162001 Tap Terminal Block (6 req’d.)
* Order by foot
PARTS LIST
Figure 4
