SkyTraq PX1172R - Pinout Description; Pinout Diagram and Description Table

5
www.skytraq.com.tw
PINOUT





PINOUTDESCRIPTION

PinNo. Name Description
1
GND 
Ground
2
RF_IN
RFinput 
3
GND 
Ground
4,5,6
NC
Noconnection,emptypin
7
VCC_RF
VoltageforexternalLNA
8,9,10,11
NC
Noconnection,emptypin
12
GND
Ground
13
NC
Noconnection,emptypin
14
GND
Ground
15,16,17,18,19
NC
Noconnection,emptypin
