ELECTRICALSPECIFICATIONS

ABSOLUTEMAXIMUMRATINGS
Parameter Minimum Maximum Condition
SupplyVoltage(VCC) ‐0.5 3.6 Volt
BackupBatteryVoltage(V_BCKP) ‐0.5 3.6 Volt
InputPinVoltage ‐0.5 VCC+0.5 Volt
InputPoweratRF_IN  +5 dBm
StorageTemperature ‐55 +100 degC



OPERATINGCONDITIONS
Parameter Min Typ Max Unit
SupplyVoltage(VDD33) 3 3.3 3.6 Volt
AcquisitionCurrent(excludeactiveantennacurrent)  100  mA
TrackingCurrent(excludeactiveantennacurrent)  100  mA
BackupVoltage(V_BCKP) 1.3  3.6 Volt
BackupCurrent(VDD33voltageapplied)  54  uA
BackupCurrent(VDD33voltageoff)  13  uA
OutputLowVoltage   0.4 Volt
OutputHIGHVoltage 2.4   Volt
InputLOWVoltage   0.8 Volt
InputHIGHVoltage 2   Volt
InputLOWCurrent ‐10  10 uA
InputHIGHCurrent ‐10  10 uA
RFInputImpedance(RF_IN)  50  Ohm












