3.10 Environmental
Temperature
Parameter
Value
Operating Temperature
-40° to +85°C
Storage Temperature
-40° to +85°C
IDP-680 and IDP-690
Parameter
Description
Humidity
The IDP-680 meets all its specifications during exposure to 90%
relative humidity at +85°C, per the test methodology of SAE
J1455, section 4.2.3.
Vibration
The IDP-680 meets all its specifications during exposure to
random vehicular vibration levels per SAE J1455, section 4.9.4.2
and MIL-STD-810G, section 514.6C-1.
Mechanical Shock
The terminal meets all its specifications after exposure to positive
and negative saw tooth shock pulses with peaks of 20G and
durations of 11 ms as specified in MIL-STD-810G, section 516.6,
Procedure I, section 2.3.2c.
Altitude
The terminal meets all of its specifications after a non-operating
12.2 km altitude test as detailed in SAE J1455, section 4.9.3,
except with an ambient temperature of -40°C.
Thermal Shock
The terminal meets all of its specifications after a thermal shock
test as detailed in SAE J1455, section 4.1.3.2.
Salt Spray
Atmosphere
The IDP-680 meets all of its specifications after a salt spray test
as detailed in SAE J1455, section 4.3.3.1.
Immersion
The terminal meets all of its specifications after a 6 hour
alternating hot/cold salt water immersion test as detailed in SAE
J1455, section 4.3.3.2.
The terminal meets all of its specifications after a 30 minute, 1 m
depth fresh water immersion test as detailed in IEC 60529,
section 14.2.7.
These immersions were performed without a cable mating with
the circular connector.
Exposure to
Chemicals and Oils
The terminal meets all of its specifications after a light to
moderate splash test as detailed in SAE J1455 section 4.4.3.2, for
the following chemicals:
 Window Washer Solvent
 Gasoline
 Diesel Fuel
 Fuel Additives
 Alcohol
 Anti-Freeze Water Mixture
