SkyWave IDP-690 - APPENDIX E IDP 600 Series Extension Cable; Figure 47 IDP 600 Series Extension Cable

IDP 600 Terminal Series - Hardware Guide
© SkyWave Proprietary 47 T200, Version 02
APPENDIX E IDP 600 Series Extension Cable
This cable (ST301017-001) allows an IDP 600 series terminal to be installed in place of a
DMR-800.
Figure 47 IDP 600 Series Extension Cable
Specifications/Guidelines
Parameter
Value
Length
500 mm ± 51 mm
Temperature
-40°C to +85°C
Material
PVC jacket, 30 mils thick, black
Ultraviolet rating
UV stabilized cable jacket
Rating
IP67 when mated
Minimum bend radius
25 mm
CAUTION Cable management and connector strain relief must be
incorporated in the installation. SkyWave highly recommends
securing the cable at regular intervals along its length as part of
the installation to prevent cable wear and eliminate strain on the
connector. Damage to the connector interface or cable may
otherwise result leading to hardware failure.
