7. On the right bottom side of the launcher (as you look at it) unzip the elevation control knob cover.
Adjust the elevation control knob to your desired launching angle - between 10º and 40º. See our
suggested positions based on level of play on pages 22 & 23..
8. Now turn ‘on’ the Launcher power switch.
9. Connect the Oscillator cable via the magnetic connector to the corresponding position on the
Launcher control panel. You will see a GREEN LED indicator come on above the oscillator
connector socket to indicate the Oscillator is connected.
10. With all of the controls set up, take the remote control and proceed to your playing position.
11. Point the remote control at the Launcher and press the top “On/Off” pickleball icon button once
in order to activate the ball feeder mechanism and press the bottom “On/Off” Oscillator icon
button in order to activate the Oscillator.
12. START PLAYING!
QUICK START LAUNCHER WITH THE OSCILLATOR
USER NOTE
After adjusting the elevation Knob please ensure that it is fully tightened before
starting the Launcher.
USER NOTE
You will hear a single “beep” to signal that the launcher wheel has started. After 10
seconds you will hear a second “beep” signalling that the feeder plate is rotating and
the balls are about to commence launching.
6
IMPORTANT
It is highly recommended to always operate the Slinger Bag using the provided
remote control for safety reasons. Please make sure not to misplace the remote.
In exceptional circumstances, such as if the remote is lost, refer to page 19 for
instructions on operating the launcher without the remote control.
Please ensure that the power is switched to “OFF” and unplugged from any electrical
connection before attempting any activity which involves reaching into the launcher
mechanism for any reason including for maintenance or cleaning.
Slinger Bag User Guide - Pickleball 2/2023
