2
ROUGH-IN — Figure 1
MODELS EAF-100/150
2.2 gpm (8.3 Lpm) Max. Flow Aerator
Faucets with Single Line Water Supply
MODELS EAF-100/150-ISM
MODELS EAF-100/150-ISM-DPU-IC
2.2 gpm (8.3 Lpm) Max. Flow Aerator
Faucets with Hot and Cold Water Supply
FAUCET SPOUT DIMENSIONS AND POP UP DETAILS
SPOUT
HOT
SUPPLY
COLD
SUPPLY
O-RING
GASKET
RETAINER
NUT
MIXING VALVE
1-3/16” (30 mm)
MIN. DIA. HOLE
REQUIRED
1-1/2” (38 mm)
MAX. DECK
THICKNESS
SPOUT
TEMPERED
SUPPLY
O-RING
GASKET
RETAINER
NUT
1-3/16” (30 mm)
MIN. DIA. HOLE
REQUIRED
1-1/2” (38 mm)
MAX. DECK
THICKNESS
5-9/16”
(142 mm)
6-7/8”
(175 mm)
24º
2-3/8
(60 mm)
2-3/4
(70 mm)
POP UP —
MODELS EAF-100/150-ISM-DPU-IC ONLY
Figure 1A Figure 1B
Figure 1C
FAUCET VARIATIONS
-ISM Integral Spout Mixer
-IC -Click Feature
-DPU Drain Pop Up
-P Plug-in Transformer (EAF-100 Series only)
PRIOR TO INSTALLATION
Prior to installing the Sloan Optima EAF-100/150 Series Faucet, install
the items listed below. Also, refer to Figures 1A thru 1C.
• Lavatory/sink
• Drain line
• Hot and cold water supply lines or pre-tempered water supply line
IMPORTANT:
• ALL PLUMBING IS TO BE INSTALLED IN ACCORDANCE WITH
APPLICABLE CODES AND REGULATIONS.
• FLUSH ALL WATER LINES PRIOR TO MAKING CONNECTIONS.
Trim Plates
When the EAF Faucet is installed on a sink that has three (3) hole
punchings, a Trim Plate should be used.
Trim
Plates
must
be
specified
and
ordered
separately.
ETF-607-A Trim Plate for 4” (102 mm) Center-set Sink
ETF-608-A Trim Plate for 8” (203 mm) Center-set Sink
TOOLS REQUIRED FOR INSTALLATION
• 13 mm open end wrench for male end of flex hose
• 13 mm open end wrench or nut driver for Faucet retainer nut
• 3/4” open end wrench for female end of flex hose
If connection to separate hot and
cold water supplies is desired, then a
Bak-Chek
®
(not supplied) must be
used prior to connecting to the
Faucet.
13” (330 mm)
LONG FLEX HOSES
13” (330 mm)
LONG FLEX HOSE
2-3/8
(60 mm)
When the EAF Faucet is installed on a sink that has three (3) hole
punchings, a trim plate should be used.
Trim
Plates
must
be
specified
and
ordered
separately:
ETF-6607-AA
Trim Plate for 4” (102 mm) Center-set Sink
ETF-6608-AA
Trim Plate for 8” (203 mm) Center-set Sink
When
installing
t
he
Faucet
on
a
three
(3)
hole
sink,
make
sure
that
the
center
hole
is
large
enough
to
accommodate
the
Faucet
shank.
A
1-33/16"
(30
mm)
minimum
diameter
hole
is
required.
NOTE
:
A
1-77/32”
(31
mm)
Diameter
hole
is
required
if
the
deck
is
greater
than
1/2”
(13
mm)
thick.
