Slugger USA101 - Operating Instructions & Contents of Package; Getting Started and Preparation

Remove all contents from packaging and inspect to ensure no damage was incurred during shipping. Your USA101
package should also include the following:
operating instructions & contents of package
description part # qty
OPERATOR’S MANUAL U14200 1
MAGNET NOTICE WARNING 0107D0C 1
SHUNT INSTRUCTIONS U14102 1
SHUNT 06556 1
WARRANTY CARD 0070342 1
HANDLE U13006 1
3/16" PILOT,
1" DEPTH OF CUT 16001 1
3/16" PILOT, 2" DEPTH OF CUT 16002 1
1/4" PILOT, 1" DEPTH OF CUT 16003 1
1/4" PILOT, 2" DEPTH OF CUT 16004 1
CARRYING CASE U13200 1
SSS 8MM X 8 FPSSS UH0804 2
SSS 10MM X 8MM UH0900 2
3MM HEX KEY UH8001 1
4MM HEX KEY UH8002 1
5MM HEX KEY UH8003 1
5MM T-HANDLE WRENCH UH8004 1
10MM COMBINATION WRENCH UH8005 1
SAFETY STRAP U11005 1
DVD LIT032 1
SPOKE HANDLE U12102 3
POWER CORD ASSEMBLY U59108 1
getting started
what you should know before you drill
CAUTION!
always disconnect usa101 from power source before making adjustments.
Assemble three spoke handles (item #18) to feed hub (item #17). See Machine Breakdown. NOTE: feed hub assembly
is mounted on right side of machine frame. If necessary, it can be mounted for left hand operation. To do so, loosen
screw until hub assembly is free (the screw will remain in the hub), move to left side and reattach hub.
Attach Removable Power Cord assembly (item #13) to socket on control panel.
1. Type of material to be drilled, Brinnell or Rockwell hardness, material thickness and position should all be
determined to ensure proper selection of Slugger cutting tools, coolant and drilling time.
2. Remove any excessive mill scale or rust from surface to be drilled.
3. When drilling materials under 3/8" thick, an additional steel plate may be required to achieve proper
magnetic adhesion.
4. Material that has been flame cut may have become heat-treated and therefore difficult to drill. Avoid drilling
near such areas whenever possible.
5. Drilling with the USA101 in horizontal positions requires a special lubrication for Slugger cutters.
Consult Jancy Engineering for details.
