Typographies
Nomenclature
Abbreviations
Figures
The figures in this document can vary slightly for inverters of types STP 1x000TL-10,
STP xx000TLHE-10, STP xx000TLEE-10, STP xx000TL-30, SB x000TL-21 and WB xx00TL-21.
Typography Explanation Example
bold • Display texts
• Elements on a user interface
•Terminals
• Elements to be selected
• Elements to be entered
• The value can be found in the
field Energy.
• Select Settings.
•Enter the value 10 in the field
Minutes.
> • Connects several elements to
be selected
• Select Settings > Date.
[Button/Key] • Button or key to be selected or
pressed
• Select [Next].
Complete designation Designation in this document
Electronic Solar Switch ESS
PV System System
SMA Inverter Inverter
Abbreviation Designation Explanation
AC Alternating Current Alternating current
DC Direct Current Direct current
