4 Product Description
4.1 485 Data Module
The 485 Data Module enables the setup of wired RS485 communication for SMA inverters.
Figure3: Design of the 485 Data Module
4.2 Type Label
The type label clearly identifies the 485 Data Module. The type label is located at the bottom right
on the back of the 485 Data Module.
Figure4: Information on the type label
Position Designation
A Hexagon socket screw
B Plug-in connector
C Plug with connected resistor
DRibbon cable plug
E Ribbon Cable
FType label
