SMA 485 Data Module - 3 Scope of Delivery; Order Option 485 Data Module Pre-Installed in the Inverter; Order Option 485 Data Module as Retrofit Kit

3 Scope of Delivery SMA Solar Technology AG
8 485i-Module-IA-en-19 Installation Manual
3 Scope of Delivery
3.1 Order Option 485 Data Module Pre-Installed in the Inverter
Check the delivery for completeness and any visible external damage. Contact your distributor if the
delivery is incomplete or damaged.
Figure1: Components included in scope of delivery: 485 Data Module pre-installed in the inverter
3.2 Order Option 485 Data Module as Retrofit Kit
Check the delivery for completeness and any visible external damage. Contact your distributor if the
delivery is incomplete or damaged.
Figure2: Components included in the scope of delivery: 485 Data Module as retrofit kit
Position Quantity Designation
A 1 Installation Manual
B 1 Technical Description "RS485 Cabling Plan"
C 1 Cable gland
Position Quantity Designation
A 1 485 Data Module with:
• 2 conductive adhesive foil labels
•1 plug
• 1 plug with connected terminator
B 1 Cable gland
C 1 Installation Manual
D 1 Technical Description "RS485 Cabling Plan"
