SMAR IF302 - Page 27

Configuration
3.11
This parameter is used
to calibrate the upper
current point. In order
to range the upper
value, simply insert the
magnetic tool in orifice
S as soon as upper is
shown on the display.
An arrow pointing
upward ( ) increment
the value and an arrow
pointing downward (
 )
decrement the value.
Apply the 20.0 mA
current in the
1 and 4
In order to
decrement
the lower
value, place
the magnetic
tool in orifice
Z to shift the
arrow to the
downward
position and
then, by
inserting and
keeping the
tool in orifice
S , it is
Figure 3.14 - Step 4 - IF302
a) In order to
decrement the
address value,
place the
magnetic tool in
orifice
Z to shift
the arrow to the
downward
position and then,
by inserting and
keeping the tool in
orifice
S , it is
possible to
Figure 3.15 - Step 5 - IF303
NOTE
This Local adjustment configuration is a suggestion only. The user may choose his preferred configuration
via SYSCON, simply configuring the display block (refer to paragraph Display Transducer Block ).
