Smartgen HGM6000K Series

HGM6000K Series Automatic Generator Module
HGM6000K Series Automatic Generator Module ISSUE 2011-06-20 Version 1.7 Page 21 of 34
Num
Parameter
Range
Default
Remark
P 32
(P27)
Gens over volt
warn
(30-360)V
256
When genset voltage is
over than the point, genset
over warning voltage is
active. When the point is
360V, genset over voltage is
disabled.
P 33
(P28)
Gens under
volt warn
(30-360)V
205
When genset voltage is
under than the point, genset
under warning voltage is
active. When the point is
30V, genset under voltage
is disabled.
P 34
(P29)
Under speed
warn
(0-6000)RPM
1350
When the engine speed is
under than the point, genset
under warning speed is
active.
P 35
(P30)
Over speed
warn
(0-6000)RPM
1650
When the engine speed is
over than the point, genset
over warning speed is
active.
P 36
(P31)
Gens under
freq warn
(0-75.0)Hz
47.0
When genset frequency is
low than the point, genset
under warning frequency is
active.
P 37
(P32)
Gens over
freq warn
(0-75.0)Hz
55.0
When genset frequency is
over than the point, genset
over warning frequency is
active.
P 38
(P33)
Charge fail
volt
(0-30)V
6.0
During genset is running,
when charge alternator
WL/D+ voltage is low than
this point and remain for 5
seconds, genset will
warning alarm.
P 39
(P34)
Battery over
volt
(12-40)V
33.0
When genset battery
voltage is over than the
point and hold for 20
seconds, battery over
voltage signal is active. It‟s
a warning alarm.
