HGM6000K Series Automatic Generator Module ISSUE 2011-06-20 Version 1.7 Page 22 of 34
Num
Parameter
Range
Default
Remark
P 40
(P35)
Battery under
volt
(4-30)V
8.0
When genset battery
voltage is less than the
point and hold for 20
seconds, battery under
voltage signal is active. It‟s
a warning alarm.
P 41
(P36)
High
temperature
warn
(80-140)ºC
95
When engine temperature
sensor value is large than
this point, send out warning
alarm. When the value is
140, send out warning
alarm. (It‟s suited for engine
temperature sensor only).
P 42
(P37)
Low oil
pressure
warn
(0-400)kPa
124
When engine oil pressure
sensor value is less than
this point send out warning
alarm. When the value is
zero, send out warning
alarm. (It‟s suited for oil
pressure sensor only)
P 43
(P38)
CT rate
(5-6000)/5
500
Current transformer rate
P 44
(P39)
Full load
current
(5-6000)A
500
Mains or genset set
maximum rated current.
P 45
(P40)
Over current
shutdown
percentage
(50-130)%
120
When the load current is
over than the point, the over
current delay is initiated.
P 46
(P41)
Over current
shutdown
delay
(0-3600)s
1296
When load current is over
than the point and hold
great than the timer, send
out over current signal.
When the delay is zero,
over current is disabled.
P 47
(P42)
Over current
warn
percentage
(50-130)%
110
When the load current is
over than the point, over
current warn icon illume.
P 48
(P43)
Switching
value output1
set
(0-11)
2
ETS solenoid to stop
P 49
(P44)
Switching
value output 2
set
(0-11)
3
Idle control
