HGM6100N Series Genset Controller User Manual Page 7 of 47
Each and total active power kW
Reactive power kvar
Apparent power kVA
Power factor PF
Generator accumulated energy kWh
Output percentage with load %
For mains, genset has functions of over/under voltage and loss of phase; For gens, genset has
functions of over/under voltage, over/under frequency, over current and over power;
Precision measure and display of parameters about engine;
Temp. (WT) °C/°F
Oil pressure (OP) kPa/psi/bar
Fuel level (FL) % Fuel remains L
Speed (SPD) r/min
Battery Voltage (VB) V
Charger Voltage (VD) V
Accumulated running hours
Accumulated start times
Control and protection function: Automatic start/stop of genset, load transfer (ATS control) and
perfect fault display and protection;
With ETS, idle control, pre-heat control, speed raise/drop control, all of them are relay outputs;
Parameter setting: Allow user to modify setting and store them in internal FLASH memory. The
parameters cannot be lost even when power off. All of parameters can be set not only from the front
panel, but also adjusted through USB interface (or RS485 interface) via PC;
Multiple sensors of temperature, pressure and fuel level can be used directly, parameters can be
defined by user;
Multiple conditions of crank disconnect (speed, oil pressure, frequency) can be selected;
With emergency start function;
With flywheel teeth numbers automatic identification function;
Power supply range: (8~35)VDC, accommodating to different starting battery voltage environment;
All parameters use digital modulation, instead of analog modulation using conventional
potentiometer, having improved reliability and stability;
With maintenance function. Types (date or running time) can be selected and actions (warning or
alarm shutdown) can be set when maintenance time out;
Event log, real-time clock, scheduled start & stop function (can be set as start unit once a
day/week/month whether with load or not);
Add rubber gasket between shell and controller screen, the waterproof can reach IP65;
Controller is fixed by metal fixing clips;
Modular design, flame-retardant ABS shell, pluggable terminal, embedded mounting, compact
structure and easy installation.
