HGM6100N Series Genset Controller User Manual Page 6 of 47
1 OVERVIEW
HGM6100N series automatic controller, integrating digital, intelligent and network techniques, is
used for automatic control and monitoring system of single genset. It can carry out functions of
automatic start/stop, data measurement, alarm protection and “three remote” (remote control, remote
measurement and remote communication). The controller uses LCD display, optional language
interface including Chinese, English, Spanish, Russian, Portuguese, Turkish, Polish and French with
easy and reliable operation.
HGM6100N series automatic controller uses micro-processing technique which can achieve
precision measurement, value adjustment, timing and threshold setting etc. All the parameters can be
configured from front panel or use USB interface (or RS485 interface) to adjust via PC. It can be widely
used in all types of automatic control system for its compact structure, simple connections and high
reliability.
2 PERFORMANCE AND CHARACTERISTICS
HGM6100N controller has six variants:
HGM6110N/6110NC/6110CAN: Automatic Start Module, it controls generator to start/stop by
remote start signal;
HGM6120N/6120NC/6120CAN: Based on HGM6110N/6110NC/6110CAN, it adds mains AC
monitoring and mains/generator automatic switching control (AMF), especially suitable for the
automation system composed by mains and genset.
NOTE1: HGM6110NC/6120NC has RS485 port, HGM6110N/6120N without.
HGM6110CAN/6120CAN has CAN port, HGM6110N/6120N and HGM6110NC/6120NC without.
NOTE2: HGM6110/6120 is taken as an example to describe in this manual.
Main characteristics are as following:
 132x64 LCD display with backlight, optional language interface (Chinese, English, Spanish, Russian,
Portuguese, Turkey, Polish and French), push-button operation;
 Acrylic screen, improved wearable and scratch resistance property;
 Silica-gel panel and keys can well adapt to higher and lower temperature;
 RS485 communication port enables “three remote” functions via MODBUS protocol;
 CANBUS port which can be connected to ECU with J1939, it not only can monitor frequently-used
data (such as water temperature, oil pressure, speed and fuel consumption, etc.) but also can
control start, stop, high speed and low speed (controller with CANBUS port is needed) via CANBUS
port;
 Adapt to 3P4W, 3P3W, 1P2W and 2P3W (120V/240V), 50Hz/60Hz system;
 Can measure and display 3 phase voltage, 3 phase current, frequency, power parameter of
mains/gens;
Mains Generator
Line voltage (Uab, Ubc, and Uca) Line voltage (Uab, Ubc, and Uca)
Phase voltage (Ua, Ub, and Uc) Phase voltage (Ua, Ub, and Uc)
Frequency Hz Frequency Hz
Phase sequence Phase sequence
Load
Current IA, IB, IC
