7. PARAMETER RANGE AND DEFINE
All parameters of HGM6100 as follows:
7.1 PARAMETERS TABLE (TABLE 1)
Num
Parameter Range Default
Remark
1 Mains normal delay
(0-3600)S 10
2
Mains abnormal
delay
(0-3600)S 5
Mains transient delay, suited for
ATS(automatic transfer switch)
3 Mains under volt (30-360)V 184
When mains voltage is under than
the point, mains under voltage is
active. When the point is zero,
mains under voltage is disabled.
4 Mains over volt (30-360)V 276
When mains voltage is over than the
point, mains over voltage is active.
When the point is 360V, mains over
voltage is disabled.
5 Transfer rest time (0-99.9S) 1.0
It’s the delay from mains is opened
to generator closing or from
generator is opened to mains
closing.
6 Start delay (0-3600s) 1
It’s the delay from remote start
signal is active or mains is failure, to
start generator.
7 Stop delay (0-3600s) 1
It’s the delay from remote start
signal is inactive or mains is normal,
to stop generator.
8 Number of Crank
(1-10)次
3 Numbers of crank cycles.
9 Preheat time (0-300)S 0
10 Cranking time (3-60)S 5
11 Crank rest time (3-60)S 10
12 Safe time (1-60)S 10
13 Start idle time (0-3600)S 0
14 Warming up time (3-3600)S 10
15 Cooling time (3-3600)S 10
16 Stop idle time (0-3600)S 0
17 ETS solenoid hold (0-120)S 20 It’s the delay for energizing to stop.
18 Fail to stop delay (0-120)S 0
19 ATS close time (0-10)S 5.0
Mains or Generator switch closing
pulse width, when it is zero, output
is continuous.
20 Flywheel teeth (10-300) 118
21
Gens Volt Abnorm
Time
0-20.0S 10.0
