Smartgen HGM6120 User Manual

HGM6110/6120 AUTO START MODULE
HGM6110/6120 Auto Start Module ISSUE 2.0 2008-10-27 Page 18 of 24
Num Content Description
1 high Temp input High engine temperature digital input
2 Low OP input Low oil pressure digit input
3 Auxiliary warn Auxiliary warn alarm digital input.
4 Auxiliary shutdown
When power on, if active, generator will stop
immediately.
5 Stop after cooled
During engine running, if the engine occur high
temperature shutdown, when the input is active, the
engine will first initiate cooling delay and then stop,
else will stop immediately.
6 Gen closed input The input state of generator closed.
7 Mains closed input The input state of Mains closed.
8 Inhibit WTH STOP
When it is active, during engine running, if the engine
occur high temperature, the engine will only send out
high temperature warning alarm, not stop.
9 Inhibit OPL STOP
When it is active, during engine running, if the engine
occur low oil pressure, the engine will only send out
low oil pressure warning alarm, not stop.
10 Reserve
7.4 SENSOR (TABLE 4)
Num Item Content Remark
1
Temperature
Sensor
0 Not used
1 Defined curve
2 VDO
3 SGH
4 SGD
5 CURTIS
6 DATCON
7 Reserve
8 Reserve
Defined curve input resistance
range is 0-
999.9 ohm, Default
is SGD
2
Oil pressure
Sensor
0 Not used
1 Defined curve
2 VDO 10Bar
3 SGH
4 SGD
5 CURTIS
6 DATCON 10Bar
7 Reserve
8 Reserve
Defined curve input resistance
range is 0-
999.9 ohm, Default
is SGD

Smartgen HGM6120 Specifications

General

Brand	Smartgen
Model	HGM6120
Category	Control Unit
Language	English
